| Integrated Circuit (IC) | |
| HCTL-2000 | |
| 2-ish | |
| • Interfaces Encoder to Microprocessor • 14 MHz Clock Operation • Full 4X Decode • High Noise Immunity: Schmitt Trigger Inputs Digital Noise Filter • 12 or 16-Bit Binary Up/ Down Counter • Latched Outputs • 8-Bit Tristate Interface • 8, 12, or 16-Bit Operating Modes • Quadrature Decoder Output Signals, Up/Down and Count • Cascade Output Signals, Up/ Down and Count • Substantially Reduced System Software | |
| www.boondog.com/…/hctl2000.pdf |
